FLOWCERT LITE Açık kanal Debimetresi
- Bentler veya savaklarla açık kanal akış ölçümü için ideal
- MCERTS Sınıf 1 sertifikalı
- Kolay montaj, basit menü odaklı kurulum
- BS3680 açık kanal akış standardını karşılar
- Kanıtlanmış temassız ultrasonik teknoloji
- Dahili bellek, 15 dakikalık aralıklarla 1 yıllık Kayıt sağlar (opsiyonel)
- Modbus ve Profibus seçenekleri
FlowCERT Lite ile kullanıcılar MCERTS Sınıf 1 onaylı 2 açık kanal akış sistemi seçeneğine sahip olurlar. Bu, sisteminizin% 0,054 doğrulukla sınıflandırılacağı anlamına gelir. , meaning that FlowCERT Lite will be giving you the most accurate reading in the world. FlowCERT Lite is ideal for open channel flow monitoring and control for a complete range of flumes, weirs, and channels.
The control unit is equipped with five user-definable relays, enabling initiation of control or indication devices such as pumps, samplers, and remote totalizers. Easy calibration for the controller can be done via the ‘Quick Set-Up’ menu and the maintenance-free ‘fit and forget’ performance means that you can install the FlowCERT Lite rapidly and with confidence.
| General Specifications | |
|---|---|
| Spec name: | Description: |
| Controller Body Dimensions: | 235 mm x 184 mm x 120 mm (9.25 in x 7.24 in x 4.72 in) |
| Weight: | 1 kg (2.2 lbs) |
| Cable Entry Detail: | 10 cable entry knock outs, 5 x M20, 1 X M16 underside, 4 x 18mm dia (PG11) at rear |
| Maximum Separation: | 1,000 m (3,280 ft) |
| Max. and Min. Temperature (Electronics): | -20 °C to +50 °C (-4 °F to +120 °F) |
| On Board Programming: | By Integral Keypad |
| Programming Security: | Via Passcode (user selectable and adjustable) |
| Power Supply: | 115 V AC +5% / -10% 50/60 Hz, 230 V AC +5% / -10% 50/60 Hz, 22-28 V DC, 10 W maximum power (typically 6 W) |
| Options | |
|---|---|
| Options: | Description: |
| MCERT Class 1 system - 0.054% accuracy | FlowCERT Lite, dB3 Transducer and external PT100 Class B3 temperature compensation sensor |
| MCERT Class 1 System - 0.193% accuracy | FlowCERT Lite, dB3 transducer with double sun shields (internal temperature compensation) |
| Industrial Automation Protocols | RS485 Modbus & Data logging Profibus and Data logging V1 |
| Data logger | SD Data Card Logger with additional logging capacity |
| Mounting brackets | Mounting bracket for transducers includes partnered transducers such as MF and dBMACH3 |
Onaylar
- MCERTS
- IP65
- CE
- Flammable Atmosphere Approval: Safe Area: Compatible with approved dB transducers
